Multilayer Pcb Design Service

Name: Multilayer Pcb Design Service
Brand: HBEONLABS TECHNOLOGIES PVT LTD
Price: 12000.0 INR
Availability: InStock

Price 12000.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Multilayer Pcb Design Service Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
10000 Pieces Per Week

Delivery Time
7 Days

About Multilayer Pcb Design Service

HBeonLabs Technologies offers comprehensivePCB Design and Project Development Services, providing complete electronic product development solutions from initial concept to a fully functional, production-ready prototype. With deep expertise in embedded systems, power electronics, IoT, and automation, we help startups, enterprises, and innovators turn ideas into real, manufacturable hardware products.

OurPCB design servicesbegin with detailedschematic capture, followed bymulti-layer PCB layoutusing industry-standard tools such asAltium Designer, KiCad, Eagle, andOrCAD. We optimize every design forsignal integrity,thermal efficiency,EMI/EMC compliance, andDesign for Manufacturability (DFM). Whether its a compact IoT sensor node, a complex industrial controller, or a high-frequency RF board, we tailor the design to your exact requirements.

Beyond PCB design, HBeonLabs offers fullproject developmentsupport, includingmicrocontroller programming,firmware development,power supply design,sensor integration,wireless communication (LoRa, GSM, Wi-Fi, BLE), andmechanical enclosure design. Our team takes care ofcomponent sourcing,prototype fabrication,assembly, andfunctional testing, ensuring that every project meets performance, quality, and cost benchmarks.

We specialize in deliveringend-to-end solutionsfor applications such as:

IoT-based monitoring and control systems
Industrial automation and process control
Solar pump controllers and smart energy devices
RFID-based access and attendance systems
Smart agriculture, healthcare, and wearable electronics

With rapid prototyping capabilities and an agile development approach, HBeonLabs Technologies helps reduce time-to-market and technical risk making us a trusted partner forinnovation, product engineering, and scalable electronics development.

Precision Engineering for Advanced PCBs

Our multilayer PCB solutions excel in accuracy and reliability. With layer counts from 2 to 12 and stringent control over board thickness, hole diameter, and trace spacing, we match your technical specifications. Materials like FR4 and Rogers offer flexibility for consumer electronics, industrial automation, or high-frequency RF applications, ensuring stable performance at typical voltages of 3.8 V and power ratings up to 3W.

A Spectrum of Finishes and Colors

Select the best surface finishHASL, ENIG, or OSPbased on your assembly and longevity needs. Bright solder masks in green, red, blue, or yellow, matched with white or yellow silkscreen, ensure clarity and easy component identification during usage. These options augment the visual appeal and function of your PCB, facilitating maintenance and manufacturability.

Tailored Services from Design to Delivery

We accept Gerber, ODB++, and DXF design files, supporting your preferred electronic CAD workflows. As an Indian manufacturer and service provider, we streamline production from prototype to high-volume supply. Our comprehensive process ensures rapid turnaround, strict quality checks, and expert support, making us a trusted partner for your multilayer PCB requirements.

FAQs of Multilayer Pcb Design Service:

Q: How do I submit a design file for multilayer PCB fabrication?

A: You can upload your PCB design in Gerber, ODB++, or DXF format. Our engineering team will review the files for compatibility with our manufacturing specifications before proceeding to production.

Q: What materials are available for the multilayer PCB boards?

A: We offer FR4, CEM-1, CEM-3, and Rogers for PCB construction, allowing customers to select the material best suited for their applications mechanical, electrical, and thermal requirements.

Q: When can I expect delivery after placing an order for multilayer PCB design?

A: Lead times depend on complexity and volume but generally range from a few days for prototypes to a couple of weeks for larger quantities. We will provide a detailed delivery schedule upon order confirmation.

Q: Where is your multilayer PCB design service located and who do you serve?

A: Our facility is based in India, and we serve clients across the country as a manufacturer, service provider, and supplier. International inquiries are also welcome depending on project scope.

Q: What is the process involved in multilayer PCB manufacturing?

A: The process includes design file review, material selection, layer stacking, drilling (min. hole size 0.2 mm), copper plating (13 oz), etching, applying solder masks and silkscreen, followed by surface finishing (HASL, ENIG, OSP) and final inspection to ensure conformity to specifications.

Q: How are the different solder mask and silkscreen colors beneficial for my application?

A: Using distinctive solder mask and silkscreen colors improves identification, facilitates assembly, and makes maintenance easier. It enhances visual contrast for component placement and troubleshooting during operation.

Q: What are the advantages of using a multilayer PCB designed by your service?

A: Our multilayer PCBs provide superior electrical performance, optimized power handling (3W), and precise voltage operation (3.8 V typical). High build quality, broad material choices, and customizable finishes ensure reliability and design flexibility for your electronic products.
